Tap the blue Power Pedal with your foot, located at the bottom left near the base of the power cord.

Tap the Vacuum Tilt release pedal to unlock the vacuum from the upright position. The blue pedal is located at the base above the left wheel.

1. Turn Vacuum OFF and unplug your vacuum.

2. To empty dirt from the dustbin canister and filters, press the Dustbin Canister Release and pull out dustbin canister.

3. Push down on the dustbin canister door release. Empty contents into trash.

4. Lift the Filter Housing Release to gain access to the HEPA and foam filters. Remove the HEPA and foam filter, tap to dislodge fine dust and then rinse under cold water as needed for a deeper clean.
Allow to FULLY dry (24hrs recommended) before re-assembling.

5. To fully clean your dustbin canister, twist the Dustbin Canister Cover Assembly and pull up to release from the dustbin. Gently dislodge any debris.

6. Replace the Dustbin Canister Cover Assembly and twist clockwise to secure to the dustbin canister.

7. Attach Dustbin Canister onto the vacuum and push back until the Canister Release clicks into place.

NOTE: Please see manual for visual illustration.

1. Remove the five screws that hold the brush roller cover.

2. Remove the brush roller cover by lifting it up.

3. Remove the brush roller by lifting the right side out of the roller guides.

4. Remove the brush roller from the belt assembly by pulling the belt towards you and sliding the brush roller out.

5. Remove all debris from the brush roller.

6. Reinstall the brush roller by inserting the left side of the roller through the belt and into the roller guides.

NOTE: Please see manual for visual illustration.

Visit the BDUR1 product page and scroll down to view an assortment of available parts and accessories for your vacuum.

You may just need to adjust the height of your vacuum.

1. Height Adjustment: Adjustable height control allows you to change the height of the floor brush depending on your floor type. When vacuuming on thick carpet, adjust toward the Tall Carpet setting. For thinner carpet and hard floor, adjust toward the Hard Floor setting. Use the adjustment to satisfy your ideal vacuuming performance.

For maximum suction power for your hose attachments, adjust the suction ring.

2. Suction Ring Adjustment: When using your vacuum tools, twist the suction ring to optimize the cleaning effect on upholstery.

3. The Dustbin Canister is full: Empty the dustbin making sure to dislodge and stuck debris.

4. The Filters are Dirty: Lift the Filter Housing Release to gain access to the HEPA and foam filters. Remove the HEPA and foam filter, tap to dislodge fine dust and then rinse under cold water as needed for a deeper clean. Allow to FULLY dry (24hrs recommended) before re-assembling.

5. The Dustbin Canister is Open: Close until release button is latched.

6. Obstruction in Hose or Brush Roller: Check the hose and brush roller for any clogs or obstructions that may be preventing air flow.

7. Broken Drive Belt: The belt connected to the roller brush may have snapped. Replace the belt.
